Torque electric screwdriver

FOB Reference Price:Get Latest Price
$300.00 - $350.00 / Sets | 1 Set/Sets (Min. Order)
Type:
Multifuctional Screwdriver
Rated Input Power:
30V
No-Load Speed:
2000r.p.m.
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China
Brand Name:
Co-share
Model Number:
SRMD-25
Power Source:
Electricity
Rated Voltage:
100-240V
Max. Torque:
0.69-2.45N.m
Weight:
<600g
Starting Mode:
Lever Start/ Push Start
Torque Range:
0.69-2.45N.m/7-25kgf.cm
Torque Adjustment:
Stepless
Screw Size(Machine Screw):
2.6~5.0mm
Screw Size(Tapping Screw):
2.6~4.0mm
Handle Diameter:
32.5mm
Length:
243.5mm
Bit Type:
A/B/D
Specification:
Standard
Torque Deviation:
The torque accuracy is ±5% of the maximum torque
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
as buyer request
Port
China Main Port
Picture Example:
package-img
package-img
Product Description

Product Application

Our product is a power tool equipped with adjusting and limiting torque to tighten and loosen screws.
It is mainly fit for high-tech precision products assembly industry of cell phones, digital cameras, laptops, PDA,LCD and computer peripherals. It is also suitable for assembling large LED/LCD display panel and large household appliance fastening industry, and assembling the interior of the vehicle. It is one of the necessary tools for most production enterprises.

Main Features

1) Brushless DC motor,long service life,maintenance free,stable torque output,suitable for clean operating environment,high stability,easy operation.

2) Small, light-weight,ergonomically designed,high temperature-resistant,vibrating-resistant,friendly holder,light ,good operation.

3) Easy to set up, complete function, user can set up this counter according to needs of work.

4) Provide with missing screw detection, floating lock detection , screw loose alarm function etc.

5) Built-in counter,rotation speed selected by swithes Hi&Lo (freely adjust),screw loose alram function.

6) Conform to Standard of CCC,optional ESD housing for all models.


Specification

Power supply
Power supply
Screw Size(Machine Screw)
2.6~5.0mm
Starting Mode
Lever Start/Push Start
Screw Size(Tapping Screw)
2.6~4.0mm
Specification
Specification
Handle Diameter
Ø32.5mm
Torque Range
0.69-2.45N.m/7-25kgf.cm
Length
243.5mm
Torque Adjustment
Stepless
Weight
<600g
Free Speed
HIGH:850
Bit Type
A/B/D
Torque Deviation
The torque accuracy is ±5% of the maximum torque
Speed Deviation
No-load speed deviation ± 10%
Detailed Images

Patent Point

1. High speed brushless DC motor to ensure the long service life.
2. The world's first built-in screw counter structure for electric screwdriver.
3.Touchless induction brake swich
